Cross Machine Tool UHPR Mod 2 HDX AR-15 Handguard - 9.5"

Manufactured by Cross Machine Tool
Manufactured by Cross Machine Tool
(0) No Reviews yet

In Stock

Orders of non-FFL items will ship same day if ordered before 3:30pm CST (M-F). FFL orders will ship within 5 business days if transfer details are provided.

For individual Officer, First Responder, and Military pricing please make sure you are logged in. for details



Cross Machine Tool has long been known for their high-quality AR-15 parts, and the new UHPR Mod 2 HDX handguards are no exception. Each rail is made of 6000-series extruded Aluminum then are hard anodized for a sleek black finish. The barrel nut is made of 7075 Aluminum, while a patented 17-4PH Cored Stainless Steel rail keeps a secure mount. Anti-rotate tabs time under the rail for timing, and when installed, the rail floats over the gas tube without any points of contact. Each handguard includes 4 QD sling sockets, with two on each side for rear and forward sling mounting. But the best part about this rail is that it only weighs 12 total ounces, hardware included. This is an incredibly lightweight mount that has all the durable materials and reliability features to assure a reliable mounting platform. Plus, all CMT MOD 2 HDX handguards are made and assembled in the USA, so rest assured that there’s a high standard of quality control. This is the UHPR-9.5 Mod 2 HDX rail, meaning that it has a 9.5” length. This is perfect for 10.5” pistols and SBRs.

  • Rail- 6000 series extruded Aluminum Milspec Type 3 Class 2 Hard Black anodized
  • Barrel Nut- 7075 Aluminum  Type 3 Class 2 Hard Anodized
  • 17-4PH  Cored Stainless Steel Rail mounting attachment-Patent Pending
  • Anti rotate tabs time Rail to upper receiver
  • 4 each Nitrided steel QD sling sockets, 2 on each side/end at the 3 o'clock & 9 o'clock positions
  • No Barrel nut shims required for installation
  • Does not contact or apply side loads to gas tube
  • Inner Diameter of handguard - 1.315"
  • MLOK Slots on all flat sides! (7)
  • Includes barrel nut wrench
  • Barrel Nut diameter- 1.378"
  • Compatible with most known low profile gas blocks
  • 9.4 oz.-Total weight including mounting hardware
  • Made & Assembled in USA

Cross Machine Tool Co., utilizing the latest machining technologies, offers high quality products that you’ll be excited to own. Cross Machine Tool is a veteran owned business that takes pride in manufacturing products you will own. CMT products exceed military standards, so you can build the best AR style rifle possible.
See More


Accessory AttachmentM-LOK
BrandCross Machine Tool
FinishHardcoat Anodized
Gas System LengthPistol
Handguard Length9.5
Inner Diameter1.315
MaterialAluminum - 6061-T6
Weight9.4 oz.
